2011-founded Tagore Technologies that pioneers high-power GaN-based RF switches, introduces a family of second-generation RF switches featuring 10W to 100W of average power. The new switches offer best-in-class insertion loss, power handling and harmonic performance.
Tagore’s TS8x family of products are best suited for post Power Amplifier (PA) harmonics filter switching for tactical and military communications (Mil Comm), land mobile radios (LMR), and private mobile radios (PMR).
Significantly reducing power consumption, lower insertion loss performance also enhances the battery life of handheld communication devices. On the other hand, lower power dissipation helps ease thermal management requirements to reduce the size, weight, and power of the overall system.
Klaus Buehring, Tagore Technology’s Chief Sales and Marketing officer, said, “Tagore’s TS8x family of switches enables customers to replace all traditional PIN diode-based switches that require many passive components and high-voltage bias supply to save significant board space and overall cost, and simplify RF front end design.”
The new family of products is pin and footprint compatible to existing products, allowing existing customers to enhance radio performance by switching to the latest generation of products.
SPECIFICATIONS:
| Specifications | TS8423K | TS8242FK | TS8441L | TS8021N |
| SPnT | SP2T | SP4T | SP4T | SP2T |
| P0.1dB_CW | 45dBm | 45dBm | 47dBm | 50dBm |
| P0.1dB_Peak | 48dBm | 48dBm | 48dBm | 52dBm |
| IL(1GHz) | 0.15dB | 0.25dB | 0.2dB | 0.20db |
| IL(3GHz) | 0.30dB | 0.35dB | 0.5dB | 0.40dB |
| Package | 3mm x 3mm | 3mm x 3mm | 4mm x 4mm | 5mm x 5mm |
