KLA Corporation (NASDAQ: KLAC) launches four new products for automotive chip manufacturing: the 8935 high productivity patterned wafer inspection system, the C205 broadband plasma patterned wafer inspection system, the Surfscan SP A2/A3 unpatterned wafer inspection systems, and I-PAT inline defect part average testing screening solution.
Modern day vehicles require more electronics than ever, which is driving the demand for semiconductor chips. With chips at the core of vehicle operations and safety applications, reliability is critical and automotive chips must meet strict quality standards.
“Today’s vehicles include thousands of semiconductor chips that sense surroundings, make driving decisions and control actions,” said Ahmad Khan, president of the Semiconductor Process Control business unit at KLA. “These chips cannot fail – a fact that has led chipmakers to pursue new strategies to find and mitigate reliability-related defects in the fab, well before the chips are integrated in vehicles. Tailored for fabs producing automotive chips, our new products detect potential reliability defects at the source and provide an innovative solution for inline screening. These actions help fabs achieve production of high quality, high reliability chips at high yield to maximize their output.”
KLA provides advanced process control and process-enabling solutions for manufacturing wafers and reticles, ICs, packaging, printed circuit boards and flat panel displays. Its three new inspectors form a complementary defect discovery, monitoring and control solution for larger design node chip manufacturing in the automotive industry.
The Surfscan SP A2/A3 unpatterned wafer inspectors incorporate DUV optics and advanced algorithms to produce the sensitivity and speed required to identify and eliminate process defects that can cause automotive chip reliability issues and to ensure process tools are operating at peak performance. For R&D and production ramp, the C205 patterned wafer inspector utilizes broadband illumination and NanoPoint technology for high sensitivity discovery of critical defects, helping speed optimization of new processes and devices. During high volume manufacturing, the 8935 patterned wafer inspector employs new optical technologies and the DefectWise AI solution to capture a wide variety of critical defects at a low nuisance rate for fast and accurate identification of process excursions that can affect final chip quality.
I-PAT is an innovative inline screening solution that runs on KLA inspection and data analytics systems. I-PAT begins by extracting defect characteristics from data collected for all wafers at critical process steps by the high speed 8 Series inspectors, including the 8935, or the Puma laser scanning inspectors. I-PAT then leverages customized machine learning algorithms on the SPOT production platform and the statistical analysis capabilities of the Klarity defect management system to identify outlier defect populations so at-risk chips can be removed from the supply chain.
“Our new products introduced today join our comprehensive portfolio of inspection, metrology, data analytics and process systems that support multiple parts of the automotive electronics ecosystem,” added Oreste Donzella, executive vice president of the Electronics, Packaging and Components (EPC) business unit at KLA. “Each one of these products plays a key role in ensuring high yield, reliability and performance of the chips, components, printed circuit boards and displays that comprise automotive electronics.”
